MARTIN AUDIO CDD-LIVE8B

2-way loudspeaker 8"/1", black, powerd 1300W, Dante, DSP, 110° hor., 60° vert. (user-rotatable)

TYPE: Ultra-compact, Coaxial Differential Dispersion powered two-way system
FREQUENCY RESPONSE: 70Hz - 20kHz ±3dB, -10dB @ 50Hz
DRIVER LF: 8" (200mm)/2" (50mm) voice coil, long excursion, shared ferrite motor system with HF
DRIVER HF: 1" (25mm) exit/1.4" (38mm) voice coil, polyimide dome compression driver
INPUT SENSITIVITY: -13dBu for 100dB SPL
MAXIMUM SPL: 117dB continuous / 123dB peak
DISPERSION: 110°-80° horizontal, 60° vertical (user-rotatable)
CROSSOVER: 2.4kHz Active LR8
PRESETS: pole mount/ pole mount with sub/ stage monitor, selection via rear panel switch
CONNECTORS: Female XLR input, male XLR link output, Dante Audio Neutrik® Ethercon
MAXIMUM ANALOGUE INPUT LEVEL: 24.6 Vpp (+21dBu), over voltage protected
DSP: PEQ/shelving filters, Up to 48dB/Oct HPF, Low latency HF FIR filters, Up to 200ms input delay
CONNECTORS: 2x Neutrik ® EtherconRJ45, PROTOCOL TCP/IP and UDP/IP
AMPLIFIER: channel switch-mode, class D
OUTPUT POWER: Peak 1300W, Continuous 650W
MAXIMUM AMBIENT TEMPERATURE: 40°C (104°F) for full output
MAINS CONNECTOR: Neutrik® Powercon True1
FINISH: Textured black PU coating.
FITTINGS: Top hat for pole mounting, 15 x M8 mounting points, Single pocket handle
DIMENSIONS: (W) 258mm x (H) 428mm x (D) 254mm
WEIGHT: 14kg
ACCESSORIES: Transit Cover
OPTIONAL: wall, yoke and universal brackets
